Side Stream Filtration Units for Closed-Loop Systems
Skid-mounted side stream filtration system for the continuous removal of magnetite and debris from large closed-loop heating and chilled water systems.
Description
Complete pre-packaged side stream filtration skids for the continuous removal of magnetite and non-magnetic debris from large closed loop heating and chilled water systems. Skid-mounted, pre-piped and ready to install.
UK stock · Same-day dispatch before 3pm · Trade accounts welcome
UKGP · IndustrialDLD-FZ · Sizes & buy
Self-cleaning side stream filters
Automatic brush-clean filtration from 19 to 1,970 m³/h. Differential pressure, time, manual or PLC control. Carbon steel or 304/316L stainless shell with 304/316L screen. Continuous filtered output even during the flushing cycle.
- Filtration
- 20 µm – 4,000 µm
- Pressure
- 0.2 – 1.6 MPa
- Cleaning
- Steel brush
- Control
- DP / Time / PLC
UKGP-SSF-01
DN50
£2,950
- Flow
- 19 m³/h
- Power
- 0.12 kW
- Weight
- 50 kg
- Height
- 1,170 mm
- Width
- 453 mm
UKGP-SSF-02
DN65
£3,250
- Flow
- 30 m³/h
- Power
- 0.12 kW
- Weight
- 70 kg
- Height
- 1,170 mm
- Width
- 453 mm
UKGP-SSF-03
DN80
£3,650
- Flow
- 50 m³/h
- Power
- 0.12 kW
- Weight
- 87 kg
- Height
- 1,210 mm
- Width
- 473 mm
UKGP-SSF-04
DN100
£4,250
- Flow
- 80 m³/h
- Power
- 0.18 kW
- Weight
- 106 kg
- Height
- 1,580 mm
- Width
- 473 mm
UKGP-SSF-05
DN150
£5,450
- Flow
- 150 m³/h
- Power
- 0.18 kW
- Weight
- 197 kg
- Height
- 1,870 mm
- Width
- 473 mm
UKGP-SSF-06
DN200
£7,250
- Flow
- 320 m³/h
- Power
- 0.25 kW
- Weight
- 248 kg
- Height
- 2,360 mm
- Width
- 617 mm
UKGP-SSF-07
DN250
£8,950
- Flow
- 490 m³/h
- Power
- 0.25 kW
- Weight
- 360 kg
- Height
- 2,490 mm
- Width
- 720 mm
UKGP-SSF-08
DN300
£11,500
- Flow
- 710 m³/h
- Power
- 0.37 kW
- Weight
- 486 kg
- Height
- 3,150 mm
- Width
- 770 mm
UKGP-SSF-09
DN350
£13,250
- Flow
- 970 m³/h
- Power
- 0.37 kW
- Weight
- 653 kg
- Height
- 3,150 mm
- Width
- 770 mm
UKGP-SSF-10
DN400
£15,250
- Flow
- 1,260 m³/h
- Power
- 0.37 kW
- Weight
- 765 kg
- Height
- 3,310 mm
- Width
- 930 mm
UKGP-SSF-11
DN450
£17,250
- Flow
- 1,600 m³/h
- Power
- 0.37 kW
- Weight
- 814 kg
- Height
- 3,360 mm
- Width
- 1,020 mm
UKGP-SSF-12
DN500
£19,500
- Flow
- 1,970 m³/h
- Power
- 0.55 kW
- Weight
- 920 kg
- Height
- 3,500 mm
- Width
- 1,020 mm
Prices ex VAT. 304/316L stainless and custom micron ratings (20–4,000 µm) available — call +44 20 8935 5572.
Benefits
Why specify our side stream filtration unit
- Fully automated sludge removal 24/7
- No filter bag or mixed media replacement costs
- Magnetic and depth filtration combined
- Pump, vessel and controls pre-assembled
- Differential pressure monitoring
- Bypass arrangement included
Typical applications
Side stream filtration specifications
- Flow rate
- 1 — 50 m³/h
- Filtration
- 5 — 100 micron
- Power
- 230V / 400V
- Controls
- IP55 panel
Automated workflow
Full automated side stream filtration and system cleaning
From continuous draw to automated cleaning and return, the skid operates autonomously to maintain water quality across the system lifetime.
Continuous Side Stream Draw
A fixed percentage of the main system flow is continuously drawn from a low-velocity point in the return pipework. This ensures representative sampling of debris and particulate from across the entire loop.
Magnetic Filtration Stage
Ferrous oxide (magnetite) and other magnetic debris are captured by a high-intensity rare-earth magnetic assembly. This is the primary defence against the black sludge that destroys seals, valves and heat exchangers.
Depth Media Filtration
Non-magnetic particulate passes through a depth-media cartridge rated from 5 to 100 micron depending on application. This removes sand, scale, installation debris and corrosion by-products.
Differential Pressure Monitoring
Integrated DP sensors continuously measure pressure loss across the filter element. As the media loads, the control system tracks performance and raises an alert when a change-out is required — no guesswork.
Automated Backwash & Cleaning
On preset intervals or DP thresholds the skid initiates an automated backwash sequence. The magnetic rod is cleaned in-situ and the media vessel is flushed to drain — all without interrupting system flow.
Clean Water Returned to System
Treated, debris-free water is returned to the main circuit at a point that promotes good distribution. The result is continuously improving water quality, reduced chemical demand and extended plant life.
System benefits
Healthier systems, lower lifetime costs.
Continuous side stream filtration removes the root cause of premature plant failure — delivering measurable improvements in water quality, energy efficiency and asset life.
Stop corrosion
Continuous removal of magnetite and oxygen-laden sludge halts the corrosion cycle inside closed loops.
Protect boilers and pipework
Cleaner system water means longer asset life for boilers, pumps, valves and heat exchangers.
Dark water to clear water
Visible improvement in water quality — black, sludge-laden circuits return to clean, clear condition.
Lower running costs
No filter bags or mixed media to swap out — eliminates the recurring consumables bill of bag filtration.
Restore plant efficiency
Removing fouling from heat transfer surfaces brings boiler and HX performance back to design duty.
Operates 24/7 unattended
Fully automated backwash and self-cleaning — no operator intervention, no system downtime.
Technical specifications
Engineered for continuous performance.
Every skid is built from robust carbon steel housings with SS304 screens, delivering reliable automated filtration with minimal water loss and uninterrupted system flow.
Filtration Precision
- Standard filtration: 20 microns
- Industrial filtration: 20–4000 microns
Materials
- Housing: Carbon steel
- Screen: SS304 stainless steel
Power & Control
- 220V / 380V / 400V
- Automated control panel
Space & Flow
- Compact footprint
- Large flow rate capacity
Backwash System
- Fully automatic backwash cycle
- Water supply continues during back flushing
Efficiency
- Water consumption < 1% of filtered water
- Pressure loss ≤ 0.02 MPa
Customisation
- Pressure ratings to specification
- Materials and power tailored to project
UK delivery
Stocked sizes — same-day dispatch from our UK warehouse for orders placed before 3pm (Mon–Fri)
12-month warranty
Manufacturer-backed defect cover
Engineer support
Sizing, drawings & site advice — free
Call the team
+44 20 8935 5572 · 8am–5pm
Buying answers
Quick answers before you order
Can't see your question? Call +44 20 8935 5572 or email sales@ukgp.co.uk — our engineers respond inside one working day.
